Working area | 2000*3000*200mm |
Spindle power | HQD 6kw ATC air-cooled spindle |
Rotating speed | 0-18000RPM |
X, Y axis transmission | High precision gear and rack |
Z-axis | Taiwan TBI ball screw |
Working table | Vacuum & T-slot working table |
Motor and driver | Leadshine 758S easy servo, Z axis with brake |
Guide rails | Hiwin 20 |
Control system | DSP A11 Controller |
Inverter | Fuling 7.5KW |
Repositioning precision | ±0.02mm |
Max travelling speed | 30000mm/min |
Max working speed | 15000 – 20000mm/min |
Working voltage | AC380V/3PH OR 220V/3PH |
Software | Original Ucancam & Copy Artcam & Copy Type3 |
Working area | 2000*3000*200mm |
Spindle power | HQD 9kw ATC air-cooled spindle |
Tool bank | Linear 4 tools bank (can update to 6 tool, 8 tools, 10 tools bank) |
Rotating speed | 0-24000RPM |
X, Y axis transmission | High precision gear rack |
Z-axis | Ball screw |
Working table | T-slot &Vacuum with one 7.5kw air vacuum pump |
Motor and driver | Leadshine 750w AC servo |
Reducer | Japanese SHIMPO Reducer (planetary gearbox) |
Guide rails | Taiwan T-win 25 square rails, X, Z axis T-win 20 rails， YYC Rack pinion |
Control system | XDW handle controller system |
Inverter | Fuling 11KW |
Other | Auto oil system Auto mist spray, auto tool sensor |
Repositioning precision | ±0.05mm |
Max travelling speed | 60000mm/min |
Max working speed | 30000mm/min |
Working voltage | AC380V/3PH |
Table size | 3050*2135mm |
Panel thickness | 5-50mm/5-30mm |
Spindle power | 9kw |
Spindle rotating speed | 24000rpm |
Dust collector | Φ150mm |
Air extraction volume | 300m3/h |
(X/Y/Z)Max travelling speed | 80m/80m/20m/min |
Vacuum pump power | 7.8kw |
Total power | 26kw |
Machine size | 4500*3200*2550mm |
Machine weight | 3200kg |
