Thickness of working board | 10 – 60mm | Thickness of PVC belt | 0.4 – 3mm |
Feeding speed | Adjustable | Min. width of working board | 60mm |
Min. length of working board | 150mm | Glue motor | 0.37kW |
End trimming motor | 0.55kW | Fine trimming | 0.75kW |
Buffing motor | 0.18kW | Air compression | 0.6 – 0.8Mpa |
Outline size of machine body | 3600 x 800 x 1800mm | Net weight | Approx. 900kg |
Option: Grooving, Auto Beam Up & Down | |||
Min/max working thickness | 12 ÷ 50 mm |
Strip edging thickness | up to 50 mm |
Coil edging thickness | 0,4 ÷ 3 mm |
Feed speed | 7 m/min |
Thickness of working board | 10 – 60mm | Thickness of PVC belt | 0.4 – 3mm |
Feeding speed | 10 – 20m/min | Min. width of working board | 60mm |
Min. length of working board | 150mm | Glue motor | 0.37kW |
Pre-milling motor | 2.2kW | End trimming motor | 0.55kW |
Rough trimming motor | 0.75kW | Fine trimming motor | 0.75kW |
Corner rounding motor | 0.37kW | Buffing motor | 0.18kW |
Air compression | 0.6 – 0.8Mpa | Outline size of machine body | 5730 x 1000 x 1800mm |
Net Weight | Approx. 2500kg | ||
Panel length | ≥ 120 mm |
Panel width | ≥ 30 mm |
Min panel size | 200*30mm(long side) 40*120mm(short side) |
Panel thickness | 9 – 60 mm |
Edge tape thickness | 0.4 – 3 mm |
Feeding speed | 16/20/24 m/min |
Dust extraction | Φ125 mm×3 |
Total power | 13 kw |
Machine Size | 4450*850*1850mm |
Panel thickness | 8 ÷ 50 mm |
Strip edging thickness | 3 mm (5mm opt) |
Thickness coil edging | 0,4 ÷ 3 mm |
Feed speed | 7 m/min |
Panel thickness | 8 ÷ 60 mm |
Max. thickness strip edges | 6 mm |
Max. thickness coil edges | 3 mm |
Feed speed | 12 m/min |
Panel length | >120mm (corner trimming on >200mm) | Dust extraction | Ø125mm*5 |
Panel width | > 40mm | Total power | 25.2kW |
Panel thickness | 9 – 60mm | Min. panel size | 350*40(long side) 40*120(short side) |
Edge tape thickness | 0.4 – 3mm | Machine size | 5960*820*1850mm |
