Description
Full log grading
Logeye 300 Multi-Sensor Quality Scanner enables log sorting according to diameter, length, curvature, taper and quality features as well as bucking and primary and secondary breakdown optimization, extracting the highest value for your plant. Rock-solid hardware, sharp optoelectronics and innovative technology give you the power to increase efficiency, maximize productivity and optimize your production-mix based upon your priorities and value parameters.
Breakdown, bucking and sorting
Logeye 300 Multi-Sensor Quality Scanner determines geometric, optical and structural qualities of a log and recognizes wood defects inside a log. This information is the basis for the powerful breakdown optimization software, Maxicut, that determines the cutting pattern with the highest quality yield. Interopt Bucking Optimization determines cross-cutting based on the highest value cutting pattern solutions in various areas within the log. Winlog Sorting Optimization enables log sorting and control of the log and merchandizing yard.
Logeye 300 Multi-Sensor Quality Scanner features
- Measures and grades logs for subsequent breakdown, bucking and sorting
- Provides a true 360° panoramic photo image of the log
- Accurately determines log density and volume over and under the bark
- Measures knottiness and other log internal features
- Increases throughput, productivity and resale of final products
Logeye 300 features Multi-Sensor cameras and sensors as well as next-generation X-ray technology to identify internal wood defects of the log. With Logeye 300 Multi-Sensor Quality Scanner you get to know your logs – before breaking them down. Logeye 300 Multi-Sensor Quality Scanner is built in modules. It consists of colour, laser and X-ray scanners. Laser interferometry can be added for improved stress grading of logs.
|
Logeye 300 features |
Logeye 301 D | Logeye 301 DC | Logeye 302 | Logeye 306 |
| Dimension (3D laser triangulation) | ✔ | ✔ | ✔ | ✔ |
| Color (360° Multi-Sensor camera) | ✔ | ✔ | ✔ | |
| X-ray (up to 2 measuring levels) | ✔ | ✔ | ||
| Improved strength grading (laser interferometer) | ✔ | |||
| Resolution | < 1 mm (0.04 in) | |||
| Image acquisition rate | Up to 1000 frames per second | |||
| Conveyor speed | Up to 300 m/min (1000ft/min) | |||
